An ESCAPADE to Mars, on the cheap

Mat Kaplan: An escapade on, or rather above Mars, this week on Planetary Radio. Welcome. I'm Mat Kaplan at The Planetary Society with more of the human adventure across our solar system and beyond. Yes, we've got yet another visit to the red planet for you. The twist is that ESCAPADE, the Escape and Plasma Acceleration and Dynamics Explorers, are budgeted far below a typical NASA Mars mission. We'll talk with principal investigator, Robert Lillis, of UC Berkeley, about how his twin spacecraft will help us understand the tortuous evolution of that world.

Mat Kaplan: Bruce Betts is anxiously waiting in the wings with a Night Sky update, one of my favorite space history events, a random space fact, and a new space trivia contest. Can you do me a favor? If you haven't already, please give Planetary Radio a rating or review in Apple Podcasts. Why there? Because it's where the most people listen to great podcasts. But we'll be happy to get your rating anywhere, really. If you've already done this, thank you.

Mat Kaplan: Sad news reported in the September 3rd edition of The Downlink. We learned a few days ago that Carolyn Shoemaker had passed away. Carolyn and her husband Gene worked steadily for many years, discovering hundreds of asteroids and 32 comets. One of those comets would get the name, Shoemaker-Levy 9. Carolyn, Gene, and their colleague, David Levy, found it shortly before it smashed into Jupiter back in 1994.

Mat Kaplan: I had the honor of talking with Carolyn at the 2013 Planetary Defense Conference. We've got a link to that episode of Planetary Radio on this week's show page at planetary.org/radio. Carolyn Shoemaker was 92. It happened too late to be included in The Downlink, but we can now confirm that Perseverance successfully collected a sample from Jezero Crater on Mars. You can expect this major accomplishment, the first of many collections to come, will be covered here on Planetary Radio and through the society's other channels.

Mat Kaplan: Want to have The Downlink sent to you for free each week? You can subscribe at planetary.org/downlink. Space is hard, Mars is harder. Getting a robot there to explore and do great science can cost a billion dollars or more. There are things only powerful sophisticated spacecraft can do, but NASA wants to find out if a much more economical approach might compliment the more expensive missions. Enter ESCAPADE, the brainchild of a team led by University of California, Berkeley research scientist, Robert Lillis.

Mat Kaplan: Rob is also the associate director of the Planetary Group at Berkeley Space Science Lab. I asked Rob to be our guest when I saw a few days ago that his mission had gotten the green light from the space agency. Here's our conversation. Rob, welcome to Planetary Radio, and congratulations on this great news for ESCAPADE. I'm looking forward to your launch, what, in 2024 if all goes well?

Robert Lillis: That's correct, Mat, and thank you very much for the kind words. Yeah. ESCAPADE is going to launch sometime in 2024. The launch date as yet and launch vehicle are both TBD, but hopefully by early next year, we will have those details all nailed down. We're excited to get going.

Mat Kaplan: Not one, but two, count them, two spacecraft for peanuts really, under $80 million. As anybody who listens to this show knows, that's nothing for an interplanetary mission, and you're sending two spacecraft. I also got to note because I'm a UC product, the Blue and Gold. Thank you for that.

Robert Lillis: Right, right. That was actually the project manager, Dave Curtis's idea. He's been at Berkeley a lot longer than I have. But yeah, we're big fans of the Golden Bears, and so blue and gold made great sense. Also, it's just more fun than spacecraft 1 and spacecraft 2.

Mat Kaplan: No question about it. What's the current status, now that you've gotten this go ahead from NASA?

Robert Lillis: Right. This was the major milestone review, or the KDPC, key decision Point to proceed to phase C. Phase C is the detailed design assembly integration test, and then leading into D, which is, I guess, the final integration and then the launch. And then phase is the operations, of course. Since the bulk of the money is spent in phase C and phase D, this is NASA's way of saying, "Okay, we've seen your preliminary design. We think this is mature enough. This is feasible. We're happy to commit to the vast majority of the rest of the budget. You have our blessing to go ahead and start moving into the detailed design and build."

Mat Kaplan: I always love to ask PIs, how did you get the word? How did you learn that NASA was saying, "You are go for launch," essentially?

Robert Lillis: Well, we were actually in the room. This was at NASA headquarters. There were 14 or 15 of us in the room at headquarters. It was chaired, of course, by the associate administrator for science, Dr. Zurbuchen. There were another maybe 60 people on the line, including all the heads of the different divisions within the Science Mission Directorate at NASA. And so, after presentations, lots of questions, presentations by the PI, by the project manager.

Robert Lillis: Also, presentations importantly by the chair of the Standing Review Board to say, "Yay, verily, we believe that this project is sufficiently mature to go ahead." And then several are probing questions from Dr. Zurbuchen, from the division head for heliophysics, Nicki Fox, the AA for programs... Sorry, the deputy AA for programs, Wanda Peters, and several other folks online as well.

Robert Lillis: Finally, at the end of a three-hour meeting, we are officially confirmed and everyone shakes hands and goes, "Yay." Then you go for drinks next door at the Hyatt, which is right conveniently next door to NASA headquarters. It was a joyous a moment. It's one of those things where you know the preliminary design review has gone well. The Standing Review Board has told you that it's gone well and that they are recommending that you go ahead.

Robert Lillis: But it's not until all the important folks within the Science Mission Directorate actually get to really examine and ask questions and give their approval, that you know it's all going to go ahead. That was a very satisfying moment for myself and for the whole ESCAPADE team.

Mat Kaplan: I bet. I bet it was even more fun than defending your PhD dissertation, from the sound of it. Okay. You've celebrated, obviously, and that was very appropriate. But now is it hitting home that you've got, what, three years to build two very sophisticated spacecraft? Which I think our audience also knows that's not a lot of time.

Robert Lillis: It's not a lot of time. I will say that ESCAPADE is an example of what NASA is trying to prove can be a legitimate model for these sorts of missions, where you accept slightly more risk. You go with commercial partners who have more common off-the-shelf approaches to things, more modular approaches to things, where they, for example, have exactly the same radio for every spacecraft that they make. They're also vertically integrated. I should say Rocket Lab are our spacecraft partners.

Mat Kaplan: Yeah.

Robert Lillis: They have an approach that's really new, what you might call commercial space entering the world of what some people call civil space, scientific space missions. Between ourselves and the other two SIMPLEx missions, Janus and Lunar Trailblazer, NASA is conducting the experiment as to whether a slightly higher risk tolerance paradigm can allow for significantly more science per dollar, bank for your book, call it what you will, but really getting a lot more science for a lot less money. And we're one of the Guinea pigs.

Robert Lillis: We are confident of our approach. NASA wouldn't have passed us if they didn't think so too. This is going to be fun. I should say that the cost for the instruments are actually very much in line for what we would have produced instruments for in the past for NASA. They are built to print instruments. They are near exact copies of prior instruments, which does bring down the cost. But we're not cutting any corners in terms of how we build the science instruments. They would be built the same as they would be for a much more expensive mission. It's much more to do with the spacecraft bus itself. That's where most of the savings come from.

Mat Kaplan: I'm going to come back to that, but we should mention that SIMPLEx, this NASA program, is Small Innovative Missions for Planetary Exploration. I read that you've complimented NASA for taking this risk with ESCAPADE and the other two missions that you mentioned. I mean, they are taking somewhat of a risk, but I would compliment them as well.

Robert Lillis: Yes. I think it is a bold move. It's a relatively small portion of the total NASA science budget, actually. It totally makes sense, as any savvy investor knows, to put a fraction of your portfolio into something that's a little higher risk and might have a higher return. So NASA is taking that almost investor approach, which is appropriate because NASA is essentially investing our tax dollars in these science missions.

Robert Lillis: NASA has been historically very risk averse. That's understandable. It's a public agency spending public money, and failures are high-profile and don't look good. So it takes, I think, that bit more courage for NASA to actually invest in a higher risk. Now I wouldn't say high-risk because we don't think it's high risk. We think it's actually very likely to succeed. It just maybe isn't the 99% or 98%. Maybe it's in the low nineties, maybe it's in the high eighties. No one knows exactly what it is yet. But it's not much more risky than what NASA has done before. We think it's an appropriate risk versus reward trade-off.

Mat Kaplan: I like that investment philosophy very much. I want to come back to Rocket Lab. A lot of people may think of it as a New Zealand company because that is where they got their start. But now of course their headquarters is from my old town, Long Beach, California, a few hundred miles south of where you are at UC Berkeley. They have, I guess, this standard spacecraft format, this bus that they call Photon, and this is part of what you're talking about, the more or less off the shelf.

Robert Lillis: Yes. That's right. The Photon bus is modeled on Rocket Lab's, upper stage, their kick stage, their third stage, if you will, from some of their previous launches. As you know, Rocket Lab has done 20-ish launches, and a number of them needed an additional kick to a higher orbit. They have had this kick stage, which before has not had solar panels because it could run on battery power, because it only had to last a few hours.

Robert Lillis: But it had all the same subsystems that a spacecraft needs to get to the right place, to know what its orientation is, to have propulsion, et cetera. What they've done is they've taken this kick stage and called it Photon and decided to essentially sell it as a science platform or a platform for other things too. I know that they have some work with the classified part of the government. Not sure what that is, but I'm sure there are other you could do with this sort of platform.

Robert Lillis: They're taking their engine. It's called it's called HyperCurie. It's a high thrust, high specific impulse engine. They're adding solar panels, of course, because we need to have a lot of power in deep space. It's becoming a standard space craft bus, except at a much lower price point. Another key aspect here is that Rocket Lab is taking a firm fixed price approach, not a cost plus approach to their contracts.

Robert Lillis: Historically, NASA science missions, the spacecraft provider is contracted using a cost-plus paradigm, where if it costs more, NASA pays. Rocket Lab thinks that they are essentially selling a service, and that the service should have a fixed price. This is also a brand new paradigm. NASA has, again, to NASA's credit, NASA has embraced this and said, "Yes, this is a paradigm we think these low-cost missions would actually really benefit from."

Robert Lillis: We're really impressed with the Rocket Lab team, us at Berkeley. They're very professional. They have excellent systems engineers, excellent subsystem engineers, thermal engineers. They're also very responsive. We're very happy working with Rocket Lab so far, and we look forward to continuing to working with them as we get into the real rubber hits the road phase of this project now.

Mat Kaplan: I look forward to visiting them someday at their headquarters down south of you. It really is my old hometown. Was for many, many years, Long Beach. Anybody who wants to see an artist's concept of the spacecraft, Blue and Gold, the two spacecraft for the ESCAPADE mission, should go to planetary.org/radio and look up the current week's episode, this episode, because we'll have images there.

Mat Kaplan: We'll have other stuff about what Blue and Gold will do once they reach Mars, and links to the press release, which is how I learned about the approval of this mission. Lots of other great resources as always at planetary.org/radio. You have some other partners in the mission as well, I saw, some other academic partners.

Robert Lillis: That's right. Indeed we do. We do. The two primary instruments, the two halves of the electrostatic analyzers are built at UC Berkeley. That's one of our bread and butter instruments, space plasma analyzer, measuring both electrons and ions. But we do, as all space plasma missions need, we need a magnetometer. We are working with our longtime colleagues at UCLA to provide that magnetometer. This is a magnetometer, there'll be one on each spacecraft at the end of a 1.3 meter long boom.

Robert Lillis: You need that kind of bloom to get away from the magnetic noise generated by the spacecraft. These are almost carbon copies of the magnetometer on the InSight Mars Lander, minus the dust cover. But yes, basically the same sensor. Built to print, very, very low-risk instrument. And then, our other major academic partner is Embry-Riddle Aeronautical University in Daytona Beach, Florida.

Robert Lillis: They are providing three different sensors comprising what we call the ESCAPADE Langmuir Probe or ELP. This is a planar ion probe to measure ion densities. This is a multi-needle Langmuir probe to measure electron densities, and also a floating potential probe to measure the high cadence changes in the electric charge on the spacecraft, which is important for interpreting the other measurements.

Robert Lillis: It is a small but highly focused for instrument package on each spacecraft, completely identical on both spacecraft. That's important because you need to make sure that you're comparing apples to apples.

Mat Kaplan: This is a great way for us to begin to talk about the science that Blue and Gold will accomplish when they're orbiting Mars. But partly as a way of getting into that, tell us a little bit about your colleague who is going to serve or is serving as the project scientist for ESCAPADE.

Robert Lillis: Dr. Shannon Curry is the project scientist on ESCAPADE, in essence, really, one of the two deputy PIs along with the very well-regarded, and highly influential, and highly well published Dr. Janet Luhmann. Shannon is serving as a project scientist. Shannon is also, perhaps more importantly, has just taken over five days ago as the PI of MAVEN from Dr. Bruce Jakosky.

Mat Kaplan: I didn't know that.

Robert Lillis: Oh.

Mat Kaplan: Yeah. Bruce has been on the show several times talking about MAVEN, and I didn't realize he'd handed off the reins.

Robert Lillis: That's right. Bruce handed off the reins to Shannon. It was about a year-long process of choosing a successor and getting Shannon integrated into all of the different financial management contractual aspects of the mission. Shannon is stepping into big shoes, but Shannon is well able for it. Shannon has a great head for not only the science, but also the dynamics of how teams work together, science teams, engineering teams, management teams, and will make a great leader for the MAVEN project.

Robert Lillis: It'll be interesting because when I wear my MAVEN hat, she'll be my boss. When she wears her ESCAPADE hat, I'll be her boss. That sort of a dynamic is pretty common in the planetary science world, which is great because it means that there's always a lot of collegiality, understanding. No one ever gets too big for their boots because someone's always your boss on something else. It's been working very, very well.

Robert Lillis: Also, there's so much synergy between MAVEN and ESCAPADE. I can get into that a little bit later in terms of the scientific synergy and actually the degree to which MAVEN kind of really set up ESCAPADE and how ESCAPADE builds on MAVEN's legacy. Shannon's going to be a great asset to both the ESCAPADE team and a great leader for the MAVEN team, on top of all the other stuff Shannon does. I mean, Shannon does a bunch of Venus stuff on Parker Solar Probe as well. She has a bunch of students. She does it all.

Mat Kaplan: We don't have to wait. I was going to bring up the fact that you are also part of the MAVEN mission, as well as the Hope mission, those other Mars orbiters there that are attempting to help us understand the atmosphere and its evolution at Mars. How will ESCAPADE complement the work that is being done by those spacecraft and others? And so, we will start getting into the science.

Robert Lillis: Let me start, first of all, on how ESCAPADE complements MAVEN and how ESCAPADE was really launched by MAVEN. Having been on the MAVEN team since almost the beginning, back when I was in grad school, we had always wanted to understand the upper atmosphere and the plasma environment of Mars, and in particular the ways in which solar energy, in the form of solar extreme ultraviolet or solar wind, the interplanetary magnetic fields, solar energetic particles, how that heliospheric environment interacts with the upper atmosphere, the ionosphere of Mars, and in particular Mars's unique crustal magnetic fields.

Robert Lillis: MAVEN was designed to study how that heliospheric environment, solar wind, solar extreme ultraviolet light, interplanetary magnetic field, solar storms, solar energetic particles, how all those affect the Mars upper atmosphere and interact with it. Mars is really a unique planet. It has what we would call a hybrid magnetosphere. Okay. Why do we say hybrid? Because it has many aspects of both an intrinsic magnetosphere, such as the Earth or Jupiter, where there is a global dipolar magnetic field generated within the core.

Robert Lillis: Typically, the magnetic field lines extend far, far beyond the planet and actually stand off the solar wind to a large multiple of radii of the planet. That's an intrinsic magnetosphere. Then there's also what we call an induced magnetosphere, such as Venus, where there is no global magnetic field, but there is a conducting ionosphere. And so, the plasma pressure within the ionosphere itself can stand off the solar wind, but the solar wind gets much, much closer.

Robert Lillis: The bow shock in front of the planet, the region where the interplanetary magnetic field piles up against the ionosphere, that's much closer to the planet than it is in an intrinsic magnetosphere. Mars has aspects of both that intrinsic and induced. The reason is Mars has these very strong, coherent, crustal magnetic fields, but not uniformly across the planet.

Robert Lillis: They're isolated mostly in the Southern Hemisphere or the strongest of them, certainly, in the Southern Hemisphere, and mostly within a relatively narrow band of longitude between about 110 degrees and about maybe 250 degrees east. So that Terra Sirenum, Terra Cimmeria area of Mars. There's these strong crustal magnetic fields, and the only way that we can explain them is coherently magnetized chunks of crust, hundreds of kilometers long, tens of kilometers wide, tens of kilometers deep.

Robert Lillis: Those result in strong magnetic fields that can push the solar wind away up to more than a thousand kilometers. But they're only really on one side at that strength. So as the planet turns, you get very different interactions with the solar wind. These magnetic fields connect and reconnect with the interplanetary magnetic field, and all that connection and reconnection results in plasma acceleration, which can give us aurora, which we're just starting to understand now.

Robert Lillis: That also helps to sometimes tear away chunks of Mars's atmosphere. These huge blobs of plasma could just be torn away by these magnetic reconnection events, and that's an important part of Mars's atmospheric loss. Of course, MAVEN's prime reason for being was to understand how Mars lost its atmosphere over time. Anyway, MAVEN has done a lot of work in understanding the different escape processes for Mars, both neutral escape, ion escape, et cetera.

Robert Lillis: ESCAPADE, really, I mean, it can't do nearly what MAVEN did. ESCAPADE is focused on that ion escape piece. When we had MAVEN, we could do a great job of measuring in situ, what was going on at any one particular place. It's like measuring the wind. You can't measure the wind just by looking at it from 10 kilometers away, unless there's clouds, I guess. But there's no clouds, wind is invisible.

Robert Lillis: Same thing with solar wind, with the plasma flows around Mars. And so, in order to measure it, you've got to be in situ. You've got to be right there. MAVEN, as one spacecraft, could either measure the solar wind conditions that were driving the system and the atmospheric escape, or it can measure the escape itself. It couldn't do both at the same time. So MAVEN allowed us to build up an average picture of what the atmospheric escape picture looked like as a function of the upstream conditions, but always separated in time by an hour, two hours, three hours, et cetera.

Robert Lillis: And so, we could never understand that real-time response because it takes only about a minute, maybe two minutes at most, for a big solar wind disturbance to propagate through the Martian system, tear away some plasma. That rich electrodynamic system, we could not measure the real-time cause and effect, and-

Mat Kaplan: Wow.

Robert Lillis: ... with ESCAPADE, we're going to be able to do that for the first time, because we'd be able to have a one spacecraft in the solar wind, and the other spacecraft right where the atmospheric escape is actually occurring. That's one really important piece of, of what ESCAPADE is doing. There's a second really important piece, and this is we can separate spatial variability from temporal variability. Okay. What do I mean by that?

Robert Lillis: If you are a spacecraft measuring either magnetic field or ion flux, and you see something change, and you're going in your orbit, you're traveling four kilometers a second, and you see something change, you see the magnetic field change, you don't know whether that's a global change that happened everywhere, or whether you've just entered a new plasma region where the conditions are different.

Robert Lillis: If you have two spacecraft in the same orbit, like a pair of pearls on a string, and you observe that change twice with two spacecraft that are maybe 10 minutes apart, you can tell whether it's a global change, because if it is, it will happen simultaneously at both spacecraft. If you're entering a new spatial region, you'll be able to see the two spacecraft enter it, or maybe the boundary of that region has moved a bit, and you'll see that too. So separating spatial from temporal variability is something that we can't do with one spacecraft. We have to have two. That's the other main thing that ESCAPADE is going to be able to achieve.

Mat Kaplan: I knew that things above Mars were very dynamic, but on the time scale of a minute or two?

Robert Lillis: Yeah.

Mat Kaplan: The other thing that occurs to me is, if you have, and I did not know this, most of that magnetic activity in that band, in the Southern portion of Mars, on concentrated on one side of the planet, it's almost as if you had a pulsar. I mean, something spinning about and affecting on each rotation of the planet, wreaking havoc in the atmosphere. It's just amazing to keep learning how very dynamic this planet is.

Robert Lillis: Yeah. I mean, the more we look, the more we learn. I'll be honest, as big as... I mean, the MAVEN team is more than a hundred scientists, and we have scratched the surface on a lot of what's going on, even just with MAVEN data. There's I'm sure plenty more to learn and plenty more PhD thesis. It's true when Mars turns its magnetic face away, or towards, or maybe side on from the solar wind, we get a really different plasma interaction, really different rates of atmospheric escape.

Robert Lillis: The models tell us that those rates of atmospheric escape change by a factor of three, maybe four at times. But those are models, and while models obviously are extremely important, we'd love to measure that real-time response to those changes in the upstream conditions for a time as when Mars's magnetic face in different orientations.

Mat Kaplan: Nothing like any real data points. Does the Hope mission, that great orbiter from the United Arab Emirates, which we have also reported on on this show, does this also figure into this research and complement what you hope to do? As I said, I know you're part of the Hope mission as well.

Robert Lillis: That's right. That's right. Yeah. The Hope mission is dealing with, I would say, the neutral escape piece of the puzzle, more so than ions. Hope doesn't measure ions, although it is sensitive to very high energy particles that are so energetic, they'll go right through a space suit and give an astronaut cancer, or they go right through the walls of an instrument and produce noise. Hope is measuring those, but those are extremely high energy. That's not really what we're talking about here.

Robert Lillis: Hope is focused on the connections between the lower and the upper atmosphere and how those connections between lower and upper atmosphere help to drive atmospheric escape, particularly neutral escape. I'm talking particularly the photochemical escape of oxygen. When I say photochemical, I mean, reactions in the ionosphere result in energetic oxygen that can escape, and that's driven by solar AUV, and then neutral escape of hydrogen as well, which is driven by just... Hydrogen is so light that the high energy thermal tail of hydrogen can escape.

Robert Lillis: That's mostly neutrals. ESCAPADE is looking mostly at the ions. Now, of course, what are ions produced from? Ions were once neutrals at one point, before they got ionized. And so, the neutral atmosphere that forms the reservoir from which ions come and from which ion escape comes, that is something that Hope is definitely looking at, things like the abundance of oxygen, carbon monoxide in the thermosphere. It's those same species that can get ionized and result in ion escape.

Robert Lillis: So while the direct measurements from Hope and ESCAPADE, we probably won't be looking very closely at them together like we would with MAVEN, they all form part of the same dynamic system where the neutrals and the ions play together to comprise this picture of upper atmospheric variability and atmospheric escape, and decoding that whole picture, that neutral and ion component of that escape is so important to understand particularly how those two different kinds of escape vary with different solar conditions, with different Martian seasons, over the course of the 11-year solar cycle, how they change with dust conditions on Mars.

Robert Lillis: Because, as we've been learning, dust now affects the upper atmosphere much more than we previously thought just in the last couple of years. Been a lot of great work on that. So understanding how that all fits together to determine the rates of escape, because unless we understand how the different channels of escape vary with all the different conditions, both planetary, in terms of dust storms, and also the influences from the sun, until we understand how all that plays together, we're not really going to be able to accurately reconstruct the history of atmospheric loss on Mars, particularly because Mars's obliquity, Mars's axial tilt, which is currently very close to the Earth's tilt.

Robert Lillis: Earth is 23.2 degrees. Mars is... Earth is 23.6 I think, Mars is 25.2, very similar right now. But Mars's can change from zero to 80, and it has over the course of Martian history. And so, the atmosphere and climate's going to look real different if you have a 60-degree tilt. And so, until we understand these processes very, very well and how those affect atmospheric escape, we can't hope to feed that understanding into the models for how that climate system would have operated under different axial tilt conditions over Martian history, to really reconstruct how Mars's atmospheric loss has changed, and therefore how the climate has evolved

Mat Kaplan: ESCAPADE principal investigator, Rob Lillis. In a minute, we'll go even deeper into Mars's dynamic atmosphere and learn about other missions that are helping Rob and the rest of us understand the red planet.

Bruce Betts: Hi again, everyone, it's Bruce. Many of you know that I'm the program manager for The Planetary Society's LightSail Program. LightSail 2 made history with its launch and deployment in 2019, and it's still sailing. It will soon be featured in the Smithsonian's new FUTURES Exhibition. Your support made this happen. LightSail still has much to teach us. Will you help us sail on into our extended mission? Your gift will sustain daily operations and help us inform future solar sailing missions like NASA's NEA Scout.

Bruce Betts: When you give today, your contribution will be matched up to $25,000 by a generous society member. Plus, when you give a hundred dollars or more, we will send you the official LightSail 2 extended mission patch to wear with pride. Make your contribution to science and history at planetary.org/S-A-I-L-O-N. That's planetary.org/sailon. Thanks.

Mat Kaplan: How much closer are we to understanding the history of the Martian atmosphere, and what all these outside forces, especially solar radiation, are still doing to it? I mean, certainly we know a lot more than we did before MAVEN got there, but clearly, there are a lot of questions left.

Robert Lillis: There are indeed, exactly. When you think about atmospheric escape from Mars and climate evolution, you need to think about the sources of atmosphere and the sinks of atmosphere, and understanding how the sources and sinks of the important items, which are oxygen, carbon, hydrogen, nitrogen also as well have changed over time. You have to understand how that all fits together. But you will also have to understand how the different isotopes of those same atoms have escaped differentially, meaning how much more nitrogen 15 has escaped compared to nitrogen 14?

Robert Lillis: How much more oxygen 18 than oxygen 16? Because you can't interpret the isotopic ratios that, for example, the SAM instrument on Curiosity has measured at the surface without knowing about how those constituents escape differently, whether they are the heavier or the lighter isotope. That's another next step beyond even where we are with MAVEN. The first thing to do is to understand the processes for how those atoms and molecules escape from Mars, both in neutral form and in ionized form.

Robert Lillis: Then we're starting to understand how they will escape differentially. And then, also, you need to have estimates about how those ratios were in terms of the sources. So the carbon, the hydrogen, the nitrogen, the oxygen that came out of the volcanoes, and the volcanic outgassing history of the planet is also important. Exactly how much mixing was there between the interior reservoirs of those gases and the atmosphere? That's also important to understand how to interpret the isotopes that we see.

Robert Lillis: What I'm getting at here is that you need to come at the problem from two different places. One, you need to say, "What are the processes causing atmospheric loss today, and how do they change with the external conditions that we see today? Can we estimate how those conditions themselves changed over history?" And the answer is yes, but there's a lot of uncertainty there. So that's never going to get us the full answer because there's too much uncertainty in terms of how the solar wind itself has changed over time.

Robert Lillis: The other direction that you come at the problem is measuring the isotopes and all the great work that both MAVEN and SAM on Curiosity have done in measuring the isotopes. Those tell you, you're like, "Yes, the lighter isotope is definitely depleted." So certainly some of this gas has escaped over time because the lighter version of it always escapes more easily. The ratio of those isotopes is usually different than it is on earth, indicating atmospheric escape.

Robert Lillis: Until we understand the processes that cause that escape, we can't interpret those isotopic measurements well enough. So we're pretty confident that something like half a bar, one bar, two bars, in that range, you could even go a little further outside that range, depending on how you probably get the uncertainties, of atmosphere has been lost from Mars over time.

Mat Kaplan: Wow. We should remind people that one bar is essentially atmospheric pressure at sea level on Earth. So we're talking a lot of atmosphere.

Robert Lillis: Right, over the history of the planet. The other difficult thing is when you say something like, "We've lost 10 to the power of 30 atoms over some length of time," of, say, oxygen. Oxygen is a component of both water, H2O, but also a component of CO2. We know that Mars has lost water because we know that the deuterium-to-hydrogen ratio is several times higher than it is on earth, indicating that plenty of water has been lost. But we also know that Mars had a much thicker CO2 atmosphere in its early history. So a lot of CO2 has been lost.

Robert Lillis: Understanding the chemical pathways that link oxygen, carbon monoxide, carbon dioxide, H2O, and then also things like HCO plus. There's other so-called proteinated ions, how all that atmospheric chemistry works together and how that chemistry changed over time and what fraction of that atmosphere was lost as ions versus neutrals, we're still a long way from unraveling all that. I don't want to call it a mess, but that rich, rich physical, chemical system.

Robert Lillis: There's many, many, many years worth of work in unraveling how the interior of Mars interacted with the atmosphere of Mars, interacted with the solar wind and the solar AUV to drive planetary evolution over the billions of years.

Mat Kaplan: And so, in all of this, we also edge closer to considering that greatest question about Mars. Was there life? Were the conditions right for the creation of life? And could it still be hiding out there today, which I know is something that you've also thought about from the angle of your own research, talking about the radiation environment at the surface and so on. I mean, you've mentioned these solar energetic particles, are SEPs, SEPs, which have been a big part of your work. You did touch on, for a moment there, the worries that we have in getting humans to Mars because of the same. This is obviously fascinating stuff to you.

Robert Lillis: Yeah. Energetic particles of Mars have been a longtime interest of mine. Actually, my introduction to the world of spacecraft missions was as deputy lead for the energetic particle detector on MAVEN. I built a substantial fraction of that instrument, and was really satisfying seeing it go to Mars, see it work as we intended it to work, and to measure the spectrum, the intensity of these solar energetic particle storms that happen on Mars.

Robert Lillis: On MAVEN, we're measuring that particle environment in orbit. And, of course, human astronauts will be in orbit around Mars, and it's important to understand the environment there. But the higher energy particles... I should say, first of all, the particles above about 10 mega electron volts, 10 or 20, will penetrate a typical space suit. So any unprotected astronauts will be subject to potentially harmful proton radiation from these steps in orbit.

Robert Lillis: You need about 130 mega electron volts, give or take. It depends on where you are in Mars, how much atmosphere happens to be above you. Like at the bottom of the Hellas Basin, there's a lot more above you than there is at the top of Olympus Mons, for example. But on average, about 130 mega electron volts or higher, those will make it down to the surface, and those will cause significant fluxes of harmful radiation.

Robert Lillis: We've worked closely with the team on the Curiosity RAD instrument. RAD stands for Radiation Assessment Detector at Mars. Over the course of the last... Oh, they've been there, what, eight years, eight or nine years now.

Mat Kaplan: Yeah.

Robert Lillis: They've measured I believe five, maybe six so-called ground level events where enough radiation has reached the surface of Mars from these energetic particles, that they've noticed a significant increase in the particle flux at the surface. They've never measured a true whopper on the surface of Mars. We think had it been there in 2003, it would have gone off the charts. The Halloween '03 event is the one that we still talk about in the Mars energetic particle community as being the huge one.

Robert Lillis: But there's this background of galactic cosmic rays, which easily make it through the Martian atmosphere. They're ever present. The highest dose rate that's been seen by the MSL RAD instrument is about maybe two and a bit times higher than That background. So, in reality, most of the energetic particle hazard for humans on the surface of Mars, at least in the last eight or nine years, has not been from SEPs because we've had a relatively weak solar max.

Robert Lillis: The solar cycle of the most recent one has been a weak one. It's those galactic cosmic rays. To get away from those, there's nothing you can do but dig underground. You've got to get about two meters of Regulus between you and those cosmic rays, to reduce the level of radiation that you're getting down to an acceptable level. Of course, this has implications for how much time human visitors, human colonists should or could spend on the surface of Mars.

Robert Lillis: But just because the most recent solar cycle has been weak doesn't mean that there aren't whoppers in our future, because there have been whoppers in our past. We're pretty sure that there have been events, even since the beginning of the space age. There was an event in 1989, I believe, that would have created a significant cancer risk on the surface of Mars, had an astronaut been there and experienced that, just from our modeling. So it's going to be a very important part of NASA's planning for human exploration of Mars.

Mat Kaplan: Not many places around the solar system or the universe that are really that friendly to life as we know it. I ran across something that indicated that maybe you discovered when Mars lost the global magnetic field, that has done such a good job of encouraging us to reach the level where we could consider traveling to Mars ourselves. How did you pin that down, and do I have that right?

Robert Lillis: Yes. I mean, there had been estimates of it before I did my thesis, but it was one of the main results of my thesis, was that I made a map of the crustal magnetic field of Mars, particularly sensitive one using a technique known as electron reflectometry. I worked with colleagues who were experts in crater age dating on Mars, who were able to look at the density of superimposed craters on any particular region of Mars and say, "We believe, actually based on Apollo samples and radiometric age dating of those samples, and associating those samples with craters on the moon, and extrapolating the size frequency distribution of the impact or population tomorrow, able to make estimates of the ages of different places on Mars."

Robert Lillis: I was able to take age map of Mars and compare it with a magnetic field map of Mars, which I had made, and looked only at the largest craters. The crater is big enough that it would definitely have reset the crater age density of that surface, and also fully reset the magnetization in those areas. And so-

Mat Kaplan: Reset just because of the heat and the energy of the impact.

Robert Lillis: The heat and the shock, exactly. I don't want to get too deep into magnetic mineralogy here, but essentially very high shock and very high temperature can remove all ferromagnetization from magnetic minerals. And then, as those minerals cool below what's known as their blocking temperature, which is related to the Curie temperature that your listeners might be familiar with, as it cools down below that blocking temperature, it acquires a magnetization both in the direction of, and with a strength proportional to the ambient magnetic field.

Robert Lillis: When I looked at the relationship between age of impact basin and magnetization of impact basin, I saw a very sharp cutoff, around 4.1 or 4.08 billion years, according to that particular cratering chronology, where every basin older than that was magnetized, and every basin younger than that was demagnetized. That told me that the basins that formed after that, there was no strong, at least global magnetic field, to speak of when those basins were formed.

Robert Lillis: And so, this gives you this tie point, whereby we estimated that Mars's global magnetic fields shut off at that point and probably didn't come back again, at least not within the timeframe of those craters. Now, there has been subsequent work done. My colleague, Dr. Anna Mittelholz, who I believe is starting at MIT soon, she's done some work looking at lava flows in a place called Lucus Planum. She has some tentative evidence that maybe the Mars magnetic field might have turned back on again around 3.7 billion years ago.

Robert Lillis: So there's still some work to be done in understanding the precise timeline of the Martian global magnetic field. But somewhere between 4.1, 3.7 billion years old Mars lost it and it didn't ever come back. Now, I'd like to correct a potential misunderstanding that I believe exists in popular culture about the role that Mars's global magnetic field played in protecting its early atmosphere.

Robert Lillis: Based on how we understood this problem several years ago, we knew that a global magnetic field is able to essentially protect much of the atmosphere from being lost via ion escape processes. That's because the magnetic field lines are closed. Plasma that goes onto those field lines can't escape. It's locked in. However, recently, there's been a concerted effort by Dr. David Brain of the University of Colorado.

Robert Lillis: He is leading a multi-institution, what's called a DRIVE Center. DRIVE is an acronym that the heliophysics division at NASA runs. I don't remember what it stands for, but he is running a detailed data and modeling effort to look at whether that's really true. Is it actually true that just because the area of the planet that is protected from ion escape, just because that area is smaller, does that mean that the total actual escape rates are going to be smaller?

Robert Lillis: Because if Mars had a global magnetic field such as we do on Earth, it can absorb a lot more energy from the solar wind, because the cross-sectional area that it presents to the solar wind is much, much bigger than it would be with no magnetic field. A lot of that energy can actually get channeled into the magnetic poles and can result in very strong electric fields that can just rip ions out of the upper atmosphere, potentially at higher rates than they would if Mars had no magnetic field.

Robert Lillis: Now, I say potentially. There's a lot of ongoing work there, things such as the gravity of the planet and the precise strength of the magnetic field. It seems as though as the magnetic field, if you were to start at a field of the strength of Earth right now, as you get weaker from that, the rate of atmospheric escape can increase for a bit, but then there's an inflection point, at least this is what some of the models tell us, where the atmospheric escape reaches a maximum. But then as you get weaker and weaker, the rates actually go down again.

Robert Lillis: And so, this is all still theoretical. One of the problems is that to get to the simulation scales, you need to accurately simulate these escape processes. Even supercomputers tend to break because you need to model things that are happening on tens of meters scales in 3D over thousands and thousands of kilometers, and even huge supercomputers can't do a great job of that.

Robert Lillis: There is various ways of parameterizing these processes and ways of getting around those difficulties, but it's a very active area of research. But the takeaway for your listeners is that magnetic fields are not the protector that we thought they were, even just a few years ago. It is an evolving field of study. I read a lot in the popular media that magnetic fields are what protected early Mars from losing its atmosphere. They definitely played a role.

Robert Lillis: Atmospheric escape was definitely very different, depending on both the strength and also the nature, whether it's dipolar, or quadripolar, octapolar. It certainly mattered, but it's not clear that it actually protected the atmosphere for as long as we think. Because remember, Mars was belching out a whole lot of stuff out of its volcanoes in those first five or six or 700 million years. Since then, it's been a trickle. So there was a lot of atmosphere being created by Mars during those times when Mars was habitable and was conducive to having life. The magnetic field, definitely part of the story, but maybe not what we once thought in terms of a protector.

Mat Kaplan: Absolutely fascinating as the paradigm continues to shift. By the way, I mean, just give it 10 years and I'm sure you'll have that supercomputer power you need to build those proper models on your smartphone. At least that's something to look forward to. There is much more to look forward to as we run short of time for our conversation. I was hoping that we could talk about the work that you've done much farther out at Europa, where that moon has to deal with that ridiculously strong magnetic field.

Mat Kaplan: But I do want to make sure that we talk a little bit about what's ahead. Obviously, you're looking forward to the launch of those two ESCAPADE spacecraft. But you had also mentioned to me some other work that you're doing, which is, I suppose, now being looked at as part of the Planetary Science Decadal Survey. It is pretty exciting stuff as well.

Robert Lillis: Right. Exactly. Mars is in, I would say, a different category to other planets because, I mean, while we don't know nearly as much as we'd like to, and we don't know nearly as much as we do about the Earth, we do know a fair bit more about Mars than we do about many of the other planetary bodies in the solar system. We're mostly past the discovery phase on Mars, and we're into the understanding phase, understanding this very complex system.

Robert Lillis: It's complex all the way from the core out to the solar wind, but let's just focus on the climate system at Mars. As part of the decadal survey, NASA asked for ideas in a program called the Planetary Mission Concept Studies Program, which was in advance of the decadal survey, whereby teams of scientists would work with teams of engineers from JPL, from APL, from Goddard, to flesh out ideas for big, like billion-dollar plus, planetary missions.

Robert Lillis: NASA selected 11 of those and they span the entire solar system, from Mercury all the way to Pluto and beyond. Two of the selectees were Mars, and one, I was armed twisted into leading a team of 50 scientists to organize this concept study effort. It was called MOSAIC or Mars Orbiters for Surface Atmosphere Ionosphere Connections. It's that connections, that C at the end, which is the important thing, because there were connections between many of the different regions, or you call them reservoirs of the Martian climate system, all the way from the shallow subsurface ice, which interacts with the surface ice, which interacts via sublimation and deposition with what's called the planetary boundary layer, or the lowest layers of the atmosphere, which interact with the water cycle, with the CO2 cycle, with the dust cycle, especially within the lower atmosphere.

Robert Lillis: As we're now learning, most recently, that dust can be lofted to much higher altitudes leading to water being lofted to much higher altitudes, which can drive the rates of atmospheric escape up by factors of 10 or 20 when you get a dust storm. Atmospheric waves that originate in the lower atmosphere can go propagate upwards and lead to changes in the loss rates of oxygen. So there's this just series of connections all the way from the ice, all the way up to the solar wind.

Robert Lillis: In order to understand that system and how it interacts, you need to make simultaneous measurements of all of it at once. And so, our idea was to send no less than 10 spacecraft to Mars and Armada, if you will, to measure this climate system. Our mission, concept, was not solely focused on science. It also had significant applicability to the human exploration of Mars too. We had a whole separate set of science goals, exploration goals.

Robert Lillis: Those exploration goals were to map out the accessible ice, because in order to make propellant, to make air, to make water, you need ice. You've got to know where the accessible ice is. The radars that have been sent to Mars up to now do not have the resolution in the shallow was 10 meters to do that. So radar mapping of ice was a big part of that.

Robert Lillis: Understanding wind. We've never measured wind except by rovers on the surface of Mars. We don't know what the wind fields of the Martian atmosphere are. We have ideas for models, but never measured wind before. So we're going to send instruments to orbit, Mars, to measure the wind. We've never measured the wind in any part of the atmosphere really, from the surface, all the way up to the thermosphere about 150 kilometers.

Robert Lillis: I should say, MAVEN has measured a few winds in the upper atmosphere, but nothing systematic. And so, this measurement of the atmosphere, the ionosphere, the surface, the solar wind, the exosphere, the rates of atmospheric escape, all simultaneously, as well as measuring the radiation environment in orbit, which as we mentioned earlier, is relevant for human exploration, for measuring the ionosphere.

Robert Lillis: That matters for human exploration because GPS doesn't work unless you have a very good model of the ionosphere, because the ionosphere distorts GPS signals. It also distorts any kind of communication signals between the Earth and an orbit. If you want to use a short wave radio and bounce your signals around the world, it bounces off the ionosphere. It travels within the cavity between the conducting surface and the conducting ionosphere. If you want to do that on Mars, you have to understand that ionosphere.

Robert Lillis: And so, really understanding the short-term variability. The Mars ionosphere was another big part of MOSAIC. Let's loop back to ESCAPADE. One thing I didn't mention earlier is that ESCAPADE, those Langmuir probes will measure, for the first time, the short-term variability of the ionosphere, which is an important piece of characterizing it sufficiently to make a GPS system, a global navigation system, work on Mars. Obviously, that's often the future, but I don't think it's that far in the future.

Robert Lillis: It's going to be an important piece of the habitation of the red planet. We're excited to be a part of that, both with ESCAPADEs=, with Hope, with MAVEN, and in the future, hopefully, with many other orbiters and also lenders, to better understand this uniquely complex climate system that Mars has.

Mat Kaplan: A great for us to end. Thank you, Rob. It has been delightful, as we consider the past of Mars and the future of science and exploration on the red planet. I hope you'll come back. We can talk another time maybe about looking farther out in the solar system and about the dangers those present both to robots and to our frail human bodies, as we look outward from our pale blue dot. Best of luck. I'm sure we will definitely want to talk again when the Blue and Gold, those two components of ESCAPADE, are ready to head for the red planet.

Robert Lillis: Well, thanks a million, Matt. I'm a huge fan of the podcast. I love what you guys do here, and I would be delighted to come back when we're a bit closer to launch. Maybe just after launch or something. That'll be great. Thanks.

Mat Kaplan: Thank you again, Rob, for those kind words, and also for taking some time out from your vacation. Go off and have a good day.

Robert Lillis: Cheers. Thanks, Matt.

Mat Kaplan: ESCAPADE principal investigator, Rob Lillis, is a research scientist at UC Berkeley, where he is also associate director of the space science lab's Planetary Group. Time for What's Up On Planetary Radio. I am joined by the chief scientist of The Planetary Society. He is also the program manager for LightSail, the LightSail program. If you missed it, you can still watch on demand. The documentary made about LightSail 2 and our whole program, it's at youtube.com/planetarysociety. You are prominently featured. Welcome.
